Airex 10″ Heavy Duty Centrifugal Inline Duct Fan — Metal, 677 CFM (XC-250)
335.000 .د.ب
The Airex XC-250 10″ (250 mm) Heavy-Duty Centrifugal Inline Duct Fan delivers 677 CFM (1,150 m³/h) against 550 Pa static pressure at 57 dB. Light-grey powder-coated metal body, 2,550 RPM single-phase 185 W motor, IP44, max ambient 65 °C. High-pressure inline for long commercial duct runs.
- Free delivery Orders over AED 200
- Manufacturer warranty Coverage on every brand
- Easy returns 7-day return window
Buying in bulk?
Open a trade account for wholesale pricing, credit terms and priority support.
Open a Trade AccountSpecifications
Additional information
| Brand | Airex |
|---|---|
| Model | XC-250 |
| Type of Fan | Centrifugal Inline Fan |
| Mounting Type | Ceiling Mount/Wall Mount |
| Voltage | 220-240V/50Hz |
| Power Consumption | 185W |
| Phase | Single |
| Body Material | Metal (Light Grey Powder-Coated) |
| Blade Material | Metal |
| Duct Size | 10" (250mm) |
| Color | Light Grey |
| Blade Speed | 2550 RPM |
| Airflow (CFM) | 677 CFM |
| Airflow (m³/h) | 1150 m³/h |
| Static Pressure | 550 Pa |
| Noise Level | 57 dB |
| Operating Environment | -10°C to +50°C |
| IP Rating | IP44 |
| Warranty | 2 Years |
| Safety Certifications | CE, RoHS |
Description
Description
Overview
The Airex XC-250 is a 10-inch metal centrifugal inline duct fan in light grey, designed for 250mm ducting. The centrifugal impeller spins at 2550 RPM to deliver 677 CFM (1150 m³/h) at a strong 550 Pa of static pressure — higher than most fans in this size class, suiting long duct runs with inline restrictions.
Construction & Materials
Round metal scroll housing in light grey with forward-curved centrifugal impeller visible inside the duct chamber. Black plastic junction box on the side houses electrical terminals. Single steel mounting foot for wall, ceiling or duct frame mounting.
Compliance & Certifications
Carries CE and RoHS certifications. Operates on 220-240V single-phase mains at 50Hz, drawing 185W at full speed. Noise output 57dB. Rated for operating environments of -10°C to +50°C. 2-year warranty.
Applications
Commercial workshops, industrial-scale grow rooms (2×2m and larger), restaurant range hood ducting, paint and welding booths, and ventilation for densely populated office floors. The high 550 Pa static pressure makes this a strong choice for runs that include carbon filters and multiple bends.
Installation Notes
Mounts horizontally or vertically along the duct run. Can be suspended with rope-ratchet hangers in grow rooms or screw-mounted to walls or ceilings. Compatible with 10-inch (250mm) flexible or rigid ducting on inlet and outlet.
